HANGING EXHAUST FAN
Our industrial exhaust fans are engineered for maximum airflow and durability. Featuring Krupp steel blades, waterproof double-row bearings, and high-strength aluminum-magnesium pulleys, these fans deliver consistent air volume with low noise and maintenance-free performance. Available with Chinese or Siemens motors (IP55 protection, F-grade insulation), and customizable voltage options. Ideal for cooling large industrial spaces efficiently with airflow up to 42,000 m³/h.
21
People watching this product now!
Description
Performance Characteristics
- Fan Blade is made of Krupp steel by punch forming, no dust, attractive and durable. Special blades shape design ensure large air volume, no deformation, no broken, keep air volume same all the way.
- Both Chinese famous motor & Siemens motor are available. Motor voltage and frequency could be customized. Motor protection grade IP55 & insulation class: Grade F
- Fan belt pulley is made of high strength aluminum-magnesium alloy by die-casting which reduces the weight of blade impeller complete, high corrosion resistance. Special three reinforced ribs pulley design. Blast-sanding treatment for an attractive appearance, eliminate internal stress to improve its own rigidity and stability, never broken.
- Fan bearing adopts imported double-row bearing with special waterproof design, water can’t enter. High strength, lower noise, maintenance-free and long-serving life.
| Model | Height (mm) |
Width (mm) |
Thickness (mm) |
Diameter Blades (mm) |
Air Flow (m³/h) |
Rated Voltage | Blades rotational speed RPM |
Motor RPM | Total Pressure (Pa) |
Noise Decibels | (W) Import Power |
| DLFB-1000 | 1000 | 1000 | 350 | 900 | 23000 | 380 | 600 | 600 | 56 | ≤60 | 550(10P) |
| DLFB-1100 | 1100 | 1100 | 350 | 1000 | 32500 | 380 | 550 | 550 | 56 | ≤60 | 550(10P) |
| DLFB-1220 | 1220 | 1220 | 350 | 1100 | 38000 | 380 | 440 | 440 | 56 | ≤60 | 750(12P) |
| DLFB-1380 | 1380 | 1380 | 350 | 1250 | 42000 | 380 | 440 | 440 | 56 | ≤60 | 1100(12P) |
