PUSH – PULL CENTRIFUGAL FAN

Description

Performance Characteristics

  •  Centrifugal makes the shutter open & close when the fan works.
  • Centrifugal shutter system is made of Nylon, high-quality engineering plastic, 100% raw material, high strength, long service life.
  • Inner still fitting install in the flange, increasing the security, avoid the stretching change when Nylon system operates.
  • Adopt the injection modeled stainless steel blades, broken & distortion proof. Aesthetic & durable.
  • The entire fan blade’s balance is checked by balance running machinery; ensure operating steady, low noise, long service life.
  • High-quality Aluminium-Magnesium Alloy inset design handle easy for carrying, transport & installation.
  • The high efficient & energy-saving motor passed the national CCC certification. Also protection class: IP55, Insulation class: F grades.
Model Height
(mm)
Width
(mm)
Thickness
(mm)
Diameter
Blades (mm)
Air Flow
(m³/h)
Rated Voltage Motor RPM Total
Pressure
Noise Decibels (W) Import Power Frequency (Hz)
DLFP-1000 1000 1000 450 910 (36in) 35000 380 1400 60 ≤64 750 50
DLFP-1380 1380 1380 450 1270 (50in) 48000 380 1400 65 ≤64 1100 50
