Axis-Q 200 2E (8″) Wall-Mounted Axial Exhaust Fan
The Blauberg Axis-Q is a powerful wall-mounted axial exhaust fan designed for efficient air movement in demanding environments. Engineered in Germany, this fan boasts an airflow capacity of up to 875 m³/h, making it perfect for high-volume ventilation tasks in commercial, industrial, or residential settings.
Its polymer-coated steel casing and aerodynamically shaped steel impeller are built to withstand harsh atmospheric conditions. The asynchronous external rotor motor ensures reliability and longevity, complete with ball bearings and automatic restart functionality.
This fan supports adjustable speed control via optional thyristor or transformer regulators, providing flexibility to suit various airflow requirements. Operating across a wide temperature range from -30°C to +60°C, it’s a dependable choice for supply, exhaust, or emergency ventilation.
Product details of Blauberg Axis-Q 200 2E (8″) Wall-Mounted Axial Exhaust Fan – 875 m³/h, High Air Volume, Germany
A strong wall-mounted axial exhaust fan, the Blauberg Axis-Q is designed to circulate air effectively in difficult settings. With an airflow capacity of up to 875 m³/h, this fan was designed in Germany and is ideal for high-volume ventilation jobs in commercial, industrial, or residential environments.
- ✅ High Capacity: Up to 875 m³/h airflow – ideal for large volume air movement
- ✅ Strong & Durable: Steel impeller and casing with atmospheric-resistant coating
- ✅ Reliable Motor: Asynchronous motor with ball bearings and auto-restart
- ✅ Speed Adjustable: Compatible with thyristor or transformer controllers (optional)
- ✅ High Temperature Tolerance: Handles air temps from -30°C to +60°C
- ✅ Versatile Use: Perfect for exhaust, supply, cooling, or firefighting ventilation systems
- ✅ Wall Mount Design: Comes with square plate and flange for surface mounting
- ✅ Moisture Protected: IPX4 ingress protection, suitable for indoor use
Technical Specifications:
| Specification | Details |
| Brand | Blauberg Germany |
| Model | Axis-Q 200 2E |
| SKU | BLB-AXIS-Q-200-2E |
| Voltage | 230V |
| Frequency | 50/60 Hz |
| Power | 55W (50Hz) / 61W (60Hz) |
| Current | 0.26A (50Hz) / 0.28A (60Hz) |
| Speed (RPM) | 2300 / 2550 |
| Air Flow | 860 / 875 m³/h |
| Sound Level | 48 / 49 dB(A) at 3m |
| Air Temp Range | -30°C to +60°C |
| Motor Type | Asynchronous motor with external rotor |
| Motor IP Rating | IP44 |
| Casing Material | Polymer-coated steel |
| Weight | 3.0 kg |
| Connection Dia. | 200 mm |
| Mounting Type | Wall mounting |
| Ingress Protection | IPX4 |
| Air Duct Compatibility | Round air ducts |
| Design Type | Axial fan |
| Application | Supply & Exhaust |
