Blauberg Axis-QA 200 (8″) Wall-Mounted Axial Exhaust Fan – High Airflow, Low Noise (32 dB), Germany
The Blauberg Axis-QA 200 is a high-performance 200mm (8″) wall-mounted axial fan for supply and exhaust ventilation. It provides a powerful 450 m³/h airflow with a low noise output of 33 dB(A). Built with a durable polymer-coated steel casing, an aluminum impeller, and an IPX4-rated motor with overheating protection, this fan is a reliable solution for efficient air circulation in residential, commercial, and industrial settings.
The Blauberg Axis-QA 200 (8″) is a high-performance wall-mounted axial fan, designed for supply and exhaust ventilation in homes, offices, and industrial spaces. Built for low static pressure applications, this fan delivers a maximum airflow of 450 m³/h, ensuring efficient air circulation with low noise levels of just 33 dB(A). The fan features a compact polymer-coated steel casing, an aluminum impeller, and an integrated overheating protection system for long-lasting reliability. With IPX4-rated moisture protection, it is ideal for indoor ventilation needs.
Product details of Blauberg Axis-QA 200 (8″) Wall-Mounted Axial Exhaust Fan – High Airflow, Low Noise (32 dB), Germany
-
Powerful Airflow: 450 m³/h maximum airflow for superior ventilation
-
Ultra Quiet Operation: Low noise level of just 33 dB(A)
-
Energy Efficient: Consumes only 33W (50Hz) / 36W (60Hz)
-
Durable & Reliable: Polymer-coated steel casing with aluminum impeller
-
Built-in Motor Protection: Overheating protection with automatic restart
-
Easy Wall Mounting: Square mounting plate and flange for quick installation
-
Flexible Speed Control: Compatible with external thyristor and auto-transformer controllers
-
Ingress Protection IPX4: Moisture-resistant and suitable for indoor use
Technical Specifications:
| Specification | Details |
| Brand | Blauberg Germany |
| Model | Axis-QA 200 |
| SKU | BLB-AXIS-QA-200 |
| Country of Origin | Germany |
| Voltage | 220-240V |
| Frequency | 50/60 Hz |
| Power Consumption | 33W (50Hz) / 36W (60Hz) |
| Current | 0.23A |
| Speed (RPM) | 1410 (50Hz) / 1654 (60Hz) |
| Maximum Air Flow | 450 m³/h (125 l/s) |
| Noise Level at 3m | 33 dB(A) |
| Fan Type | Axial impeller |
| Casing Material | Polymer-coated steel |
| Impeller Material | Aluminum |
| Motor Type | Single-phase asynchronous motor with internal rotor |
| Static Pressure | Low-pressure application |
| Max. Operating Temperature | -30°C to +40°C |
| Mounting Type | Wall mounting |
| Ingress Protection | IPX4 |
| Weight | 2.82 kg |
